Rubber Lined Pipe & Non Metallic Linings
Rubber lined steel pipe is an alternative to the rubber hose for the straighter sections of a slurry system.
RUBBER LININGS AND COATINGS
The rubber lined steel pipe is available in various lengths. The rubber lined steel pipe does not need a support beam, only supports at each end.
The standard protective rubber lining used in slurry applications are lined with a natural or Synthetic rubber. Characteristics Rigid steel pipes lined with long‐life wear rubber with smooth walls and low flow resistance.
We specialize in working with customers to protect their equipment and assets in the industrial market.
We lead the way in being committed to utilizing the most advanced technology to evaluate, safely prepare and apply long term protective coatings. Storage tanks and piping-interior/exterior coatings and linings.
Rubber Lined Pipe & Non Metallic Linings
PROTECTIVE COATINGS
Natural Rubber
Soft – Semi –Hard
Soft
Strengths
- Excellent abrasion resistance.
- Good Resistance too many acids and alkalis.
- Remains flexible @ low temperatures.
- Good resistance to mechanical and thermal shock -Lower in price than most other linings.
Weaknesses
- Easy to install and repair.
- Sunlight, oxidation/ozone resistance.
- Ingredients can be added to improve properties.
- Oxidizing acids (nitric and chromic).
- No resistance to oil or hydrocarbons.
- Resistance to temperatures above 180F.
Applications
- Mining
- Slurry Pipe
- Chutes
- Thickeners
- Clarifiers & Mills
- Chemical Services
- High Abrasion
- Aggregates
- Shaking Tables
- Steel Works
Semi & Hard
Strengths
- Good Resistance to Chemicals.
- Good heat resistance up to 212F.
- Low water absorption.
- Low permeation rate.
- Moderate cost.
- Moderate Oil Resistance.
Weaknesses
- Poor abrasion resistance.
- Poor low temperatures.
Applications
- Mining
- Slurry Pipe
- Chutes
- Thickeners
- Clarifiers & Mills
- Chemical Services
- High Abrasion
- Aggregates
- Shaking Tables
- Steel Works
Synthetic Rubbers
PC-35
This lining is designed for the harshest conditions. It will provide protection against abrasion, chemical resistance, and hydrocarbons.
- Proprietary Blended CSM 55 Shore A Durometer.
- Provides Greater Cross Linking.
- Can handle greater concentrations of hydrocarbons than CR.
- Abrasion Resistance.
- DIN value 73.
- Compares to high abrasion compounds used in Mill Liners.
- Resistance to a majority of acids.
- Heat Resistance up to 310°F (155°C).
Applications
- Mining
- Slurry Pipe
- Chutes
- Thickeners
- Clarifiers
- Chemical Services
- High Abrasion
- Oil & Gas
Chlorobutyl
Chlorobutyl rubber exhibits a high level of heat and heat aging resistance to 225°F. It has good resistance to a broad array of general chemical solutions at 180-220°F.
Because butyl rubber is nonpolar, it will swell upon contact with lubricating oils and fuels.
Strength
- Excellent oxidation and ozone resistance.
- Very low permeation rate.
- Low water absorption.
- Good resistance to temperatures – 260°F.
- Good resistance to a wide variety of chemicals.
Weaknesses
- No resistance to oils or hydrocarbons.
- Costs more than natural rubbers.
Applications
- High Heat Chemical Applications
- Chemical Industry
- Power Generation
Neoprene
Neoprene’s have flame resistance, weather ability, ozone resistance and swelling resistance to mineral, vegetable, and animal oils.
In lining services with general chemical exposure, CR has heat resistance to 220°F with strong acids (sulphuric acid) and 200° F with strong bases (sodium hydroxide).
Strengths
- Excellent oxidation, UV, ozone resistance.
- Moderate oil resistance.
- Fire resistance.
- Good abrasion resistance.
- Good low temperature properties and high temperatures up to 212°F.
- Hot tables are required to preshrink the lining.
Weaknesses
- High material costs.
- Could be difficult to install.
Applications
- Hydro Carbon Applications
- Chemical Industry
- Power Generation
- Mining
- Cement Industry
- Cyclones
- Thickeners
- Slurry & Tailing Lines
- Floatation Cells
Bromobutyl
Bromobutyl is a derivative of the halobutyl family, which is structurally similar to chlorobutyl rubber and produced through the same halogenation process: By using the brominated process allows the same workability in the lining as a chlorobutyl.
As well with the brominated process these linings have the key ingredient “Exxon Mobile 2255". The Exxon Mobile 2255 Bromobutyl polymer will exhibit stronger physical characteristics over other Bromobutyl polymer linings.
The Proco Bromobutyl’s are both “pure" in polymer content, which means there is no other polymer in the formulation: The Exxon Mobile 2255 Bromobutyl polymer is 55% of the formula.
Advantages
- Low glass transition temperature
- Wide vulcanization versatility
- Fast cure rates
- Higher Heat Resistance
- Stronger bond strength to substrates
- Excellent Oxidation / Ozone
- Resistance
- Good Abrasion Resistance
- Tight knitting of the molecular cross link w/ low permeability rate
- Constant temperature of 127°F and handle spikes up to 150°C
Applications
- High Heat Chemical Applications
- Chemical Industry
- Power Generation
Nitrile
Nitrile rubber (NBR) is a product formed by the copolymerization of acryl nitrile and butadiene. Many grades of NBR are available in which the acryl nitrile content varies from 18 to 51% by weight.
The addition of acryl nitrile enhances swelling resistance and impermeability. NBR is a polar-type rubber used where exposure to aliphatic hydrocarbons is a service condition. NBR exhibits good resistance to swelling when immersed in liquids that are non – or weakly polar, such as gasoline, grease, mineral oil, and animal or vegetable fats and oils.
Polar and aromatic solvents attack NBR. It should not be used with such aromatic solvents as: benzene, toluene, or xylene. NBR is less permeable to gases than natural rubber or SBR rubber.
However, it exhibits significantly improved heat and aging resistance to a level of 260 degrees F.
Applications
- Hydro Carbon Applications
- Chemical Industry
- Power Generation
- Mining
- Cement Industry
- Cyclones
- Thickeners
- Slurry & Tailing Lines
- Floatation Cells
Protective Coatings
Polyurea
Polyurea is an organic polymer that is the reaction of isocyanate with an amine terminated polyether resin, forming a plastic-like or rubber-like compound that may be used in many of the same ways as older technologies – polyurethane, epoxy, vinyl ester, neoprene; to name a few.
A polyurea coating/elastomer is that derived from the reaction product of an isocyanate component and a resin blend component. The isocyanate can be aromatic or aliphatic in nature.
It can be monomer, polymer, or any variant reaction of isocyanates, quasi-prepolymer or a prepolymer.
The prepolymer, or quasi-prepolymer, can be made of an amine-terminated polymer resin, or a hydroxyl-terminated polymer resin. The Resin blend must be made up of amine-terminated polymer resins, and/or amine terminated chain extenders.
The amine-terminated polymer resins will not have any intentional hydroxyl moieties. Any hydroxyls are the result of incomplete conversion to the amine-terminated polymer resins. The resin blend may also contain additives, or non-primary components.
These additives may contain hydroxyls, such as pre-dispersed pigments in a polyol carrier. Normally, the resin blend will not contain a catalyst(s).
Applications
Airports / Power Plants /Refineries / Structural Steel / Fertilizer Plants / Warehouse Floors / Mining Operations / Cold Storage Facilities Food Processing Plants /Landfill Containment /Marine Environments Paper and Pulp Mills /Secondary Containment /Parking Garage Decks / Walkways and Balconies Water and Waste Water Treatment Industrial and Manufacturing Facilities / Slurry Tanks.
Epoxy
Is either any of the basic components or the cured end products of epoxy resins, as well as a colloquial name for the epoxide functional group.
Epoxy resins, also known as polyoxides, are a class of reactive prepolymers and polymers which contain epoxide groups. Epoxy resins may be reacted (cross-linked) either with themselves through catalytic photopolymerization, or with a wide range of co-reactants including polyfunctional amines, acids (and acid anhydrides), phenols, alcohols and thiols.
These co-reactants are often referred to as hardeners or curatives, and the cross-linking reaction is commonly referred to as curing. Reaction of polyoxides with themselves or with polyfunctional hardeners forms a thermosetting polymer, often with high mechanical properties, temperature and chemical resistance.
Epoxy has a wide range of applications, including metal coatings, use in electronics / electrical components/LED, high tension electrical insulators, paint brushes manufacturing, fiber-reinforced plastic materials and structural adhesives.
Applications
Airports / Power Plants /Refineries / Structural Steel / Fertilizer Plants / Warehouse Floors / Mining Operations / Cold Storage Facilities Food Processing Plants /Landfill Containment /Marine Environments Paper and Pulp Mills /Secondary Containment /Parking Garage Decks / Walkways and Balconies Water and Waste Water Treatment Industrial and Manufacturing Facilities / Slurry Tanks.
PC Flex
Two Component Hybrid Bromobutyl Liquid Rubber designed for excellent chemical resistance and heat resistance up to 110°C / 230°F. Commonly used for Conveyor Belt Repairs.
- 2 Hour Self Cure.
- 18 Volt 10:1 Caulking Gun.
- 110°c Heat Resistance.
- No Adhesives Required.
- Physical Properties Durometer 50 (+/-5) Shore A Tensile 1,800 PSI Elongation 400%.
PC FLEX Dispense Gun
Product Type
Dual Component Application: Two-Part Cartridge Weight: 10 lbs. Capacity: 750 ml. Mix-Ratio(s): 10:1 Mix Ratio.
Features
Applications
Conveyors Belt Repair / Rubber Lining Repair / General Coatings / Tank Lining Repairs / Cyclones / Chutes / Rubber Hoses Repair / Aggregate Industry / Cement Industry.
PCK-094 Pipe / Tank Leak Repair
A two-part component, 100% solid, thermoset system. This high-quality system is designed for the emergency metal repair of leaking pipes, tanks, stripped threads, and bearing seats.
094 – can be drilled, tapped and 094 filed or machined while exhibiting excellent mechanical properties.
Super-Fast 094 is a n easy to mix trowel able putty. Bonds to ferrous and non – ferrous metal surfaces Resistant to many common chemicals including acids, bases and alkalis.
- Applies easily to vertical surfaces.
- Machinable to metallic finish.
- Maximum Service Temp 200°F.
- Working Time 3 Minutes.
- Functional Cure 1 Hour.
- Mix Ratio 1:1 by Volume.
- Hardness 86 D.
- ASTM D 2240.
- Color: Gray.
- Viscosity: Paste.
Once fully cured, the material will demonstrate good resistance to a broad range of commonly found chemicals. The surface to be coated must be free of all rust, scale, dirt, dust, grease, oil, release agents, or other contaminants.
For smooth surfaces or where vibration is a concern, tack weld an open mesh screen or expanded metal approximately 1/16 to 1/8 inch above the surface. Chip off weld slag.
Applications
Water Line Repair / Slurry Lines External Repair / Tailings Line Exterior Repair / Lime Slurry Exterior Repair / Hydro Transport Line Repair / Chemical Industry / Metal Exterior Repair.
PM-200 Neoprene Repair
200PM: Designed as an Abrasion Resistant repair for extreme abrasion applications where hydrocarbons are present to get increased life until proper repairs can be made.
PC-200PM is a two-part flexible polymer filling compound. Due to the rapid cure there can be early put load on the assembled parts.
The components are processed manually or by means of suitable metering and mixing machines. This can be used on existing liners for patch repairs or leading edge repair.
Applications
High Abrasion Repair / Hydrocarbon Applications / Slurry Lines / Tailings.
Rubber Liners
PC-140
40 Durometer Black Natural Rubber– Specifically designed to withstand Chemical and Abrasion concerns.
This compound demonstrates excellent characteristics for corrosion and abrasion concerns.
PC-160
60 Durometer Black Natural Rubber– Specifically designed to withstand Chemical and Abrasion concerns.
This compound demonstrates excellent characteristics for corrosion and abrasion concerns.
PC-260
60 Durometer Highly Engineered Bromobutyl Lining– Exhibits excellent characteristics against high heat, high concentrations of acid and abrasion resistance.
PC-261
60 Durometer High Temperature Hybrid Chlorobutyl– Specifically designed for Chemical and Abrasion concerns at higher temperatures.
PC-262
60 Durometer High Abrasion Hybrid Chlorobutyl– Specifically designed for enhanced abrasion resistance specifically in high wear applications.
PC-355
60 Durometer High Temperature Chlorosulfonated Polyethylene (Hypalon, CSM)– Specifically designed for high Chemical and Abrasion concerns at extreme temperatures.
